High-quality adhesive transfer tape supply

Product description

◔ This product serie is directly coated with acrylic adhesive on the release liner without any carrier. The tape is transparent in color, has excellent bonding effect, preventing residues, oozing and other defects. It is good for punching and die cutting applications; widely used in general industrial assembly, bonding of membrane switch, nameplates and electronic parts.

Product features

◔Anti-rebound, resistance to warping, heat resistance and temperature resistance

◔ Highly transparent

◔ Strong adhesion and holding power

◔ Good bonding effect to multiple kinds of carrier materials

High-quality adhesive transfer tape supply-2

◆ Application

High-quality adhesive transfer tape supply-3

FPC bonding and fixation

Suggested Model: NC767

This model is 50 ~ 55μm thick, dry texture, good for punching and die cutting application; stable bonding effect to all kinds of carrier materials; good bonding to FPC.

High-quality adhesive transfer tape supply-4

Membrane switch bonding

Suggested Model: NC768

Relatively dry texture, good for punching and die cutting application; stable bonding effect to all kinds of carrier materials, such as membrane, plastics or metal.

High-quality adhesive transfer tape supply-5

Metal sheet temporary bonding and fixation

Suggested Model: NC768A

This model is 128 ~132μm thick and relatively soft, strong bonding effect, especially suitable for the bonding of foam materials.

◆Parameter table

Model

Tape thickness(mic)

Color

Initial Tack(mm)

Peeling Force(N/24mm)

Holding Power(hour)

Temp. Resistance(℃)

Remarks

NC767

50-55

Transparent

>=50

>=10

>=24

White release liner, relatively hard texture, suitable for die-cutting and punching.

NC767N

50-55

Transparent

<=100

>=10

>=24

Yellow kraft paper, good initial tack, suitable for the bonding of all kinds of plastic and metal panels.

NC768

128-132

Transparent

<=150

>=13

>=24

White release liner, relatively dry, good film-forming property, suitable for die-cutting and punching.

NC768N

128-132

Transparent

<=100

>=13

>=24

Yellow kraft paper, good initial tack, suitable for the bonding of all kinds of plastic and metal panels.

NC767G

50-55

Transparent

<=100

>=11

>=24

White release liner, suitable for the bonding of all kinds of plastic and foam materials.

NC767A

50-55

Transparent

<=100

>=11

>=24

White release liner, strong adhesion, suitable for the bonding of all kinds of plastic and foam materials.

NC768A

128-132

Transparent

<=150

>=14

>=24

White release liner, strong adhesion, suitable for the bonding of all kinds of plastic and foam materials.

NC767G-1

50-55

Transparent

<=100

>=9

>=24

White release liner, relatively hard texture, suitable for die-cutting and punching.

Disclaimer:

The product technical data are for reference only. Actual performance may differ depending on factors beyond our expectation and control.
