Thermal Conductive Tape

A white adhesive tape made of glass fiber cloth as the base material, coated on both sides with acrylic adhesive.

Features
● The soft and conformable base material allows it to fill uneven surfaces effectively.
● It offers high bonding strength, making it suitable for attaching and securing components that require thermal conduction and heat dissipation.

Inquiry

Write a Review

Applications

Bonding heat-dissipating parts of LED lights

Panel lights

Attaching thermal management components

Product Series

Model	Thickness (μm)	Color	Initial adhesion (mm)	Adhesion (N/24mm)	Holding power (hour)	Temperature resistance (℃)
DS36-6100L	200	White	≤100	≥12	≥24	80
DS36-6100L	250	White	≤100	≥14	≥24	80
DS36-7050L	150	White	≤100	≥16	≥24	80
DS36-7050L	200	White	≤100	≥18	≥24	80
DS36-7050L	250	White	≤100	≥20	≥24	80
DS36-7050L	300	White	≤100	≥22	≥24	80
DS36-7050L	350	White	≤100	≥24	≥24	80
DS36-7100L	200	White	100	≥13	≥24	80
DS36-7100L	250	White	≤100	≥15	≥24	80
