Application Scope
CROWN Adhesive Tape's double coated tape can be used in multiple scenes.CROWN Adhesive Tape insists on providing customers with one-stop and complete solution from the customer's perspective.We guarantee that all of our products can meet the with strict QC procedure strictly conducted.
Company Advantages1. With specialized design, PI tape manifests its stylish characteristic.
2. The product is rather safe. It corners and edges are all rounded by professional machines to reduce sharps, hence causing no injury.
3. This product can significantly protect the feet from sharp objects and uncomfortable surfaces, which will help people fight against the tough roads.
Product description
◔ This product serie uses tissue/PET/PI as the carrier and acrylic adhesive is evenly coated on both sides, and the laminated with release liner. It has strong adhesion and holding power, good bonding effect to different types of materials; suitable for punching, bonding of nameplates, membrane switch and automobile accessories with fireproof requirements.
◔Strong adhesion
◔ Strong holding power.
Bonding of heat insulation material for the car
Suggested Model: DS10B6F
Flame retardant standard up to UL94 VTM-0 and FMVSS 302≤100mm/min. It has strong holding power and good adhesion to various kinds of materials, including plastics and metal.
Membrane switch bonding and fixation
Suggested Model: DS10B6F
Flame-retardant with strong adhesion and holding power; good bonding effect to different types of materials; suitable for bonding for punching application, nameplates and membrane switch.
Model | Tape thickness(mic) | Color | Initial Tack(mm) | Peeling Force(N/24mm) | Holding Power(min) | Flame Retardant Standard | Remarks |
DS10B6F | 100+/-5 | Transparent | <=200 | >=10 | >=30 | Fmvss302 | Strong adhesion and holding power, good bonding effect to different types of materials. |
DS10B6F | 120+/-5 | Transparent | <=200 | >=12 | >=50 | Fmvss302/ UL94VTM-0 |
DS10B6F | 130+/-5 | Transparent | <=200 | >=13 | >=50 | Fmvss302/ UL94VTM-0 |
DS10B6F | 140+/-5 | Transparent | <=200 | >=14 | >=50 | Fmvss302/ UL94VTM-0 |
DS10B6F | 160+/-5 | Transparent | <=200 | >=16 | >=50 | Fmvss302/ UL94VTM-0 |
DS35-7025FY | 200+/-5 | Transparent | <=150 | >=16 | >=200 | Fmvss302/ UL94VTM-0 | Flame retardant with PI carrier, strong adhesion, suitable for the bonding of all kinds of foam and lint materials. |
Disclaimer: The product technical data are for reference only. Actual performance may differ depending on factors beyond our expectation and control. |
