◔ The product serie uses PET as the carrier and acrylic adhesive is evenly coated on single side or double sides, and then laminated with release liner. It is mainly used in the bonding and fixation of nameplates and membrane switch in the household appliance industry.
◔Good initial tack and holding power, easy of die cutting.
◔ Good anti-aging and UV light resistance, moisture resistance.
◔ Excellent resistance to shear at both high temperature and low temperature; strong tensile strength.
Metal nameplate bonding and fixation
Suggested Model: 6025DT
Sandwich structure, good bonding strength and peeling force; good for die cutting and punching application.
Membrane switch bonding and fixation
Suggested Model: 7025DT
Sandwich structure, good bonding strength and peeling force; good for die cutting and punching application.
Microwave door label
Suggested Model: 6025ST
Single coated tape, high bonding strength, excellent anti-rebound feature, good for die cutting and punching application; microwave oven panel bonding for protection and radiation protection.
Internal bonding of Exterior mirror
Suggested Model: DS31-6025AM
Good bonding strength and holding power, temperature resistance; suitable for the internal bonding of resistor plate and the exterior mirror.
| Model | Tape thickness(mic) | Color | Initial Tack(mm) | Peeling Force(N/24mm) | Holding Power(hour) | Temp. Resistance(℃) | Remarks | |||||
6DT Serie Sandwich Double coated Tape | ||||||||||||
| 6025DT | 125+/-5 | Transparent | <=180 | >=14 | >=24 | 80 | Strong adhesion; suitable for the bonding of nameplates and membrane switch. | |||||
| 6038DT | 138+/-5 | Translucent | <=180 | >=13 | >=24 | 80 | Suitable for the bonding of nameplates and membrane switch. | |||||
| 6050DT | 150+/-5 | Translucent | <=180 | >=13 | >=24 | 80 | ||||||
| 6075DT | 175+/-5 | Transparent | <=180 | >=12 | >=24 | 80 | Suitable for the bonding of nameplates and decorative parts. | |||||
| 6100DT | 200+/-5 | Translucent | <=180 | >=11 | >=24 | 80 | ||||||
| 6125DT | 225+/-5 | Translucent | <=180 | >=10 | >=24 | 80 | ||||||
| 6175DT | 275+/-5 | Translucent | <=180 | >=9 | >=24 | 80 | ||||||
| 6188DT | 288+/-5 | Translucent | <=180 | >=8 | >=24 | 80 | ||||||
7DT Serie Sandwich Double coated Tape | ||||||||||||
| 7025DT | 125+/-5 | Transparent | <=180 | >=14 | >=24 | 120 | Strong adhesion; long-term resistance to high temperature at 120℃; suitable for the bonding of nameplates and membrane switch. | |||||
| 7038DT | 138+/-5 | Translucent | <=180 | >=13 | >=24 | 120 | Long-term resistance to high temperature at 120℃; suitable for the bonding of nameplates and membrane switch. | |||||
| 7050DT | 150+/-5 | Translucent | <=180 | >=13 | >=24 | 120 | ||||||
| 7075DT | 175+/-5 | Transparent | <=180 | >=12 | >=24 | 120 | Long-term resistance to high temperature at 120℃; suitable for the bonding of nameplates, decorative parts and articles. | |||||
| 7100DT | 200+/-5 | Translucent | <=180 | >=11 | >=24 | 120 | ||||||
| 7125DT | 225+/-5 | Translucent | <=180 | >=10 | >=24 | 120 | ||||||
| 7175DT | 275+/-5 | Translucent | <=180 | >=9 | >=24 | 120 | ||||||
| 7188DT | 288+/-5 | Translucent | <=180 | >=8 | >=24 | 120 | ||||||
| 6ST Serie Single coated Tape | ||||||||||||
| 6025ST | 75+/-5 | Transparent | <=180 | >=14 | >=24 | 80 | For surface protection of all kinds of surfaces, such as the transparent door panel protection for microwave or electric oven. The tape thickness can be chosed by client's demand. | |||||
| 6050ST | 100+/-5 | Translucent | <=180 | >=13 | >=24 | 80 | ||||||
| 6075ST | 125+/-5 | Transparent | <=180 | >=12 | >=24 | 80 | ||||||
| 6100ST | 150+/-5 | Translucent | <=180 | >=11 | >=24 | 80 | ||||||
| 6125ST | 175+/-5 | Translucent | <=180 | >=10 | >=24 | 80 | ||||||
| 6175ST | 225+/-5 | Translucent | <=180 | >=9 | >=24 | 80 | ||||||
| 6188ST | 238+/-5 | Translucent | <=180 | >=8 | >=24 | 80 | ||||||
DS31 Serie Double coated Tape | ||||||||||||
| DS31-6025 | 125+/-5 | Transparent | <=180 | >=14 | >=24 | 80 | Strong adhesion; suitable for the bonding of all kinds of nameplates and membrane switch. | |||||
| DS31-6038 | 138+/-5 | Transparent | <=180 | >=13 | >=24 | 80 | Suitable for the bonding of all kinds of nameplates and membrane switch. | |||||
| DS31-6050 | 150+/-5 | Transparent | <=180 | >=13 | >=24 | 80 | ||||||
| DS31-6075 | 175+/-5 | Transparent | <=180 | >=12 | >=24 | 80 | Suitable for the bonding of nameplates and decorative trims. | |||||
| DS31-6100 | 200+/-5 | Transparent | <=180 | >=11 | >=24 | 80 | ||||||
| DS31-6125 | 225+/-5 | Transparent | <=180 | >=10 | >=24 | 80 | ||||||
| DS31-6175 | 275+/-5 | Transparent | <=180 | >=9 | >=24 | 80 | ||||||
| DS31-6188 | 288+/-5 | Transparent | <=180 | >=8 | >=24 | 80 | ||||||
Disclaimer: The product technical data are for reference only. Actual performance may differ depending on factors beyond our expectation and control. | ||||||||||||
